Jemi Glasswashers
-
GS – 5 AF Glasswasher
Dimensions (mm): 480 x 555 x 720
Dimensions of rack (mm): 400 x 400
Usable height (mm): 290
Output/hour: 1000 glasses
Total power (Kw): 2,97
Boiler heating element (Kw): 2,6
Tank heater power (Kw): 2,4
Wash pump power (Kw): 0,37
Voltage: 230 V / II / 50 – 60 Hz
-
GS-16 Glasswasher
Dimensions (mm): 580 x 650 x 820
Dimensions of rack (mm): 500 x 500
Usable height (mm): 380
Output/hour: 1.440 glasses
Total power (Kw): 3,34
Boiler heating element (Kw): 2,6
Tank heating element (Kw): 2,4
Wash pump power (Kw): 0,74
Voltage (single phase): 230 V / II / 50 – 60 Hz
-
GS-17 Glasswasher
Dimensions (mm): 580 x 650 x 820
Dimensions of rack (mm): 500 x 500
Usable height (mm): 380
Output/hour: 1440 glasses
Total power (Kw): 5,24
Boiler heating element (Kw): 4,5 / 6
Tank heating element (Kw): 4,5
Wash pump power (Kw): 0,74
Voltage: 230-400 V / III / 50 – 60 Hz
-
GS-18 Glasswasher
Dimensions (mm): 580 x 650 x 820
Dimensions of rack (mm): 500 x 500
Usable height (mm): 380
Output/hour: 1440 glasses
Total power (Kw): 3,34
Boiler heating element (Kw): 2,6
Tank heating element (Kw): 2,4
Wash pump power (Kw): 0,74
Voltage: 230 V / II / 50 – 60 Hz
-
GS-19 Glasswasher
Dimensions (mm): 580 x 650 x 820
Dimensions of rack (mm): 500 x 500
Usable height (mm): 380
Output / hour: 1440 glasses
Total power (Kw): 5,24
Boiler heating element (Kw): 4,5 / 6
Tank heating element (Kw): 4,5
Wash pump power (Kw): 0,74
Voltage: 230-400 V / III / 50 – 60 Hz
-
GS-5 Glasswasher
Dimensions (mm): 480 x 555 x 670
Dimensions of rack (mm): 400 x 400
Usable height (mm): 220
Output/hour: 1000 glasses
Total power (Kw): 2,71
Boiler heating element (Kw): 2,6
Tank heating element (Kw): 2,4
Wash pump power (Kw): 0,11
Voltage (single phase) 230 V / II / 50 – 60 Hz
-
GS-6AF Glasswasher
Dimensions (mm): 480 x 555 x 720
Dimensions of rack (mm): 400 x 400
Usable height (mm): 290
Output / hour: 1.000 glasses
Total power (Kw): 2,97
Boiler heating element (Kw): 2,6
Tank heating element (Kw): 2,4
Wash pump power (Kw): 0,37
Voltage (single phase): 230 V / II / 50 – 60 Hz
